| Ordering SKUs |
TVS-882ST3-i7-16G |
TVS-882ST3-i7-8G |
TVS-882ST3-i5-8G |
| CPU |
Intel® Core™ i7-6700HQ quad-core 2.6 GHz, up to 3.5 GHz |
Intel® Core™ i5-6442EQ quad-core 1.9 GHz, up to 2.7 GHz |
|
Encryption Accleration
|
Yes, AES-NI |
| System Memory |
16GB (2 x 8GB) |
8GB (2 x 4GB) |
| Maximum Memory |
32GB (2 x 16GB) |
| Number of Memory Slots |
2 x DDR4 SODIMM slots
(For dual-DIMM configuration, you must use a pair of identical DDR4 modules.) |
| Flash |
512MB |
| Drive |
8 x 2.5" SATA 6Gb/s HDD/SSD |
| Thunderbolt Port |
2 x Thunderbolt 3 |
| 10GbE LAN Port |
2 x 10GBASE-T |
| GbE LAN Port |
2 x Gigabit RJ45 |
| USB 3.1 Port |
1 x Type-C USB 3.1 Gen2 10Gbps
1 x Type-A USB 3.1 Gen2 10Gbps |
| USB 3.0 Port |
2 |
| LCM Display |
Yes |
| PCIe Slot |
2 (1 PCIe 3.0 x8 + 1 PCIe 3.0 x4)
Note: Pre-installed with a Thunderbolt 3 card and a 10GbE card |
| HDMI Port |
1, up to 3846 x 2160, 30Hz |
| Audio Input |
3.5mm microphone input jack |
| Audio Output |
3.5mm line out jack |
| LED Indicators |
Status/Power, USB, Drive 1-8 |
| Buttons |
Power, USB copy, reset, select, enter |
| Infrared Receiver |
Yes, supplied with QNAP RM-IR004 remote control |
| Other Interfaces |
Kensington security slot, maintenance port |
| Dimension (HxWxD) |
177 x 180 x 235 mm
6.97 x 7.09 x 9.25 inch |
| Weight |
Net (NAS only): 3.97 kg (8.75lbs) |
| Operating Temperature |
0 ~ 40˚C (32˚F ~ 104˚F) |
| Relatie Humidity |
5~95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
| Sound Level (dB) |
15.2 dB (A) |
| Power Consumption |
HDD sleep: 26.36W
Typical operation: 43.43W |
HDD sleep: 25.57W
Typical operation: 42.70W |
| Power Supply |
ATX 250W, Input: 100V-240V ~ / 3.5A, 50Hz-60Hz |
| Fan |
1 x 12 cm (12V DC) |
