| CPU |
AMD® 2.4GHz quad-core x86 processor with Radeon™ graphics |
| DRAM |
TVS-863+-8G: 8GB DDR3L-1600 x 1
TVS-863+-16G: 16GB DDR3L-1600 (8GB x 2)
Total memory slots: 2
Memory expandable up to: 16 GB (8GB x2)
NOTE: For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide.
|
| Flash Memory |
512MB DOM |
| Hard Disk Drive |
8 x 3.5”or 2.5”SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE:
1. The system is shipped without HDD.
2. For the HDD compatibility list, please visit www.qnap.com/compatibility |
| Hard Drive Tray |
8 x Hot-swappable tray |
| LAN Port |
2 x Gigabit RJ-45 Ethernet port (Onboard:2, expandable to max 4 ports by replacing the pre-installed PCI-E NIC)
1 x 10 Gigabit port (Preinstalled PCIe NIC)
|
| PCIe Slot |
1 (PCIe Gen2 x 4) |
| LCD Panel |
Mono-LCD display with backlight, Enter and Select buttons for configuration
|
| LED Indicators |
Status, LAN, USB, HDD 1-8 |
| USB |
5 x USB 3.0 port (Front: 1, Rear: 4)
Support USB printer, pen drive, and USB UPS etc. |
| HDMI |
2 (Mirrored Display), 1.4a
Note: 4K video playback and transcoding are not supported |
| Buttons |
Power/Status, USB One-Touch-Backup, reset |
| Alarm Buzzer |
System warning |
| IR Receiver |
QNAP RM-IR002 and MCE-compatible remotes
|
| Form Factor |
Tower
|
| Dimensions |
185.2(H) x 298.2(W) x 235.4(D) mm
7.29(H) x 11.74(W) x 9.27(D) inch
|
| Weight |
Net:7.83 kg (17.26lbs)
Gross: 8.9 kg (19.62lbs) |
| Power Consumption(W) |
S3 sleep: 2.84W
HDD standby: 48.21W
In operation: 77.60W
(with 8 x 2TB HDDs installed) |
| Temperature |
0-40˚C |
| Humidity |
5~95% RH non-condensing, wet bulb: 27˚C |
| Power Supply |
ATX 250W, 110-240V AC, 50-60Hz, 5A |
| Secure Design |
Kensington security slot for theft prevention |
| Fan |
2 x quiet cooling fan (12cm, 12V DC) |
 |
