HP Трансивер HP X132 10G SFP+ LC SR Transceiver (J9151A)

 Ports1 LC 10-GbE port (IEEE 802.3aq Type 10Gbase-LRM); Duplex: full onlyConnectivityConnector typeLCWavelength1310 nmPhysical characteristicsDimensions2.19(d) x 0.54(w) x 0.47(h) in. (5.57 x 1.38 x 1.19 cm)Weight0.04 lb. (.02 kg)Transceiver form factorSFP+EnvironmentOperating temperature32°F to 158°F (0°C to 70°C)Operating relative humidity0% to 85%, noncondensingNonoperating/Storage temperature-40°F to 185°F (-40°C to 85°C)Altitudeup to 10,000 ft. (3 km)Electrical characteristicsPower consumption typical0.7 WPower consumption maximum1 WCabling

Cable type:
62.5/125 µm or 50/125 µm (core/cladding) diameter, graded-index, low metal content, multimode fiber optic, complying with ITU-T G.651 and ISO/IEC 793-2
Type A1b or A1a, respectively (a mode conditioning patch cord may be needed in some multimode fiber installations);
Maximum distance:

• 0.5-220m with 62.5 µm multimode cable @ 160/500 MHz*km
• 0.5-220m with 62.5 µm multimode cable @ 200/500 MHz*km
• 0.5-100m with 50 µm multimode cable @ 400/400 MHz*km
• 0.5-220m with 50 µm multimode cable @ 500/500 MHz*km
• 0.5-220m with 50 µm multimode cable @ 1500/500 MHz*km

Cable length0.5m to 220mFiber typeMulti ModeNotes

For OM3 cable (50 µm multimode @ 1500/500 MHz*km), a mode-conditioning patch cord is not required. Other multimode cables may require mode-conditioning patch cords to achieve the maximum distances listed above.
For fiber patch cords, use Ultra Physical Contact (UPC) surface termination/polish. Angled Physical Contact (APC) is not recommended.

ServicesRefer to the HP website at: www.hp.com/networking/services for details on the service-level descriptions and product numbers. For details about services and response times in your area, please contact your local HP sales office.

---
