Каталог - Платы расширения и аксессуары - Интерфейсный мост ATTO XstreamCORE ET 8200/8200T (XCET-8200-002/XCET-8200-TP2)



Интерфейсный мост ATTO XstreamCORE ET 8200/8200T (XCET-8200-002/XCET-8200-TP2)

Цена: 1842750 р
Наличие: Под заказ
Артикул: XCET-8200-002
Производитель:ATTO
Cпецификация: Скачать PDF-файл

 Technology:

  • xCORE™ Acceleration Technology to eliminate bottlenecks
  • eCORE™ Control Engine adds common, open storage services
  • XstreamVIEW™ Storage Manager for easy remote configuration, management and diagnostic capabilities
  • Host LUN Mapping initiator to LUN mapping
  • Drive Map Director™ patented SAS device mapping
  • Support for Extended Copy (LID1) to offload CPU, memory and storage fabrics
  • Supports iSER (iSCSI Extensions over RDMA)
  • Support ATTO's Hardware Accelerated iSCSI
  • XstreamCORE uses ATTO patented technology (US Patents #US7836225B2, US8291132B2, US7788324B2, US8504770B2)

Host Connectivity:

  • Two 40Gb/s Ethernet ports
  • Auto negotiates to 40Gb, 10Gb or 1Gb Ethernet
  • Includes two optical 40Gb/s QSFP+ modules
  • Multi-initiator access for all attached storage

Storage Connectivity:

  • Four x4 12Gb/s Mini-SAS HD connectors (16 phys)
  • Supports SAS processor devices
  • Supports up to 240 drives (extendable to 960 for qualified customers)
  • Supports SAS and SATA flash solid state disk drives (SSD) (not supported on ET 8200T)
  • Supports SAS and SATA hard disk drives (not supported on ET 8200T)
  • Supports SAS Tape Drives and Libraries
  • Supports SAS/SATA Optical Drives (not supported on ET 8200T)
  • Supports RAID arrays (Multiple LUNs behind a target)

Performance:

  • Up to 6GB/s sustained transfer rate
  • Up to 1.1M 4K IOPS per controller
  • 2 microsecond end-to-end latency

Management:

  • Support for DMTF Redfish and SNIA Swordfish™ management
  • SNMP and SNMP MIB support
  • Built in temperature monitoring
  • Statistic Reporting for SAS and Ethernet ports

Physical:

  • Top-of-rack controller
  • Dual hot-swappable power supplies
  • No batteries
  • RoHS Compliant
  • Advanced integration available for OEM applications
  • 2 year standard product warranty
  • Optional 5 year total warranty and advanced replacement available
