SPECIFICATIONSProduct Category
NVR Storage Appliance
Availability
Released
Ideal Camera Range
32 to 64
Form Factor
2U6, 19” rackmount
Drive Support
SATA (6Gb/s or 3Gb/s), NCQ, TCQ
(Initiator still runs at 3Gb/s mode) System Processor
Intel® Core™ i3 Dual-core
System Memory
8GB Standard (max. 16GB)
Max. # of HDDs Supported
118
(Expansion through iSCSI and multiple JBOD expansion enclosures) RAID Levels
0, 1, 1E, 3, 5, 6, 10 (0+1), 30, 50
Supported OS (64-bit)
Windows Embedded Standard 7 Runtime (WS7P), Windows Server 2008/2012 R2 Standard, Windows Storage Server 2012R2 Standard
Power Supply
500W (Three redundant 250W N+1 design), 1288 BTU/hr
Dimensions
88.2 x 440 x 400 mm (3.5 x 17.3 x 15.7 in)
Weight
10.4kg(22.9 lbs) w/o drives, 14.9kg (32.8lbs) w/drives
Warranty
3 years and EW plans
|
