| Hardware Specifications |
| CPU |
| CPU Model |
INTEL Atom C2538 |
| CPU Frequency |
Quad Core 2.4 GHz |
| Floating Point |
|
| Hardware Encryption Engine (AES-NI) |
|
| Memory |
| System Memory |
2 GB DDR3 |
| Memory Module Pre-installed |
2 GB X 1 |
| Total Memory Slots |
2 |
| Memory Expandable up to |
6 GB (2 GB + 4 GB) |
| Storage |
| Drive Bay(s) |
12 |
| Maximum Drive Bays with Expansion Unit |
24 |
| Compatible Drive Type |
- 3.5" SATA(III) / SATA(II) HDD
- 2.5" SATA(III) / SATA(II) HDD
- 2.5" SATA(III) / SATA(II) SSD
|
| Maximum Internal Raw Capacity |
72 TB (6 TB HDD X 12) (Capacity may vary by RAID types) (See All Supported HDD) |
| Hot Swappable Drive |
|
| External Ports |
| USB 3.0 Port |
4 |
| Expansion Port |
1 |
| File System |
| Internal Drives |
EXT4 |
| External Drives |
|
| Appearance |
| Size (Height X Width X Depth) |
270 mm X 300 mm X 340 mm |
| Weight |
9.24 kg |
| Others |
| RJ-45 1GbE LAN Port |
4 (with Link Aggregation / Failover support) |
| Wake on LAN/WAN |
|
| System Fan |
120 mm X 120 mm X 2 pcs |
| Easy Replacement System Fan |
|
| Wireless Support (dongle) |
|
| Noise Level* |
27.1 dB(A) |
| Power Recovery |
|
| Scheduled Power On/Off |
|
| Power Supply Unit / Adapter |
500W |
| AC Input Power Voltage |
100V to 240V AC |
| Power Frequency |
50/60 HZ, Single Phase |
| Power Consumption* |
73.44W (Access)
37.13W (HDD Hibernation) |
| Environment Temperature |
| Operating Temperature |
5°C to 35°C (40°F to 95°F) |
| Storage Temperature |
-20°C to 60°C (-5°F to 140°F) |
| Relative Humidity |
5% to 95% RH |
| Certification |
- FCC Class B
- CE Class B
- BSMI Class B
|
| Warranty |
3 Years |
| Notes |
- Power consumption is measured when fully loaded with Western Digital 1TB WD10EFRX hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate 1TB ST31000520AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
|
| DSM Specifications ( See more ) |
| Storage Management |
| Maximum Single Volume Size |
108 TB |
| Maximum Internal Volume Number |
512 |
| Maximum iSCSI Target Number |
32 |
| Maximum iSCSI LUN |
256 |
| iSCSI LUN Clone/Snapshot, Windows ODX |
|
| Supported RAID Type |
- Synology Hybrid RAID
- Basic
- JBOD
- RAID 0
- RAID 1
- RAID 5
- RAID 6
- RAID 10
|
| RAID Migration |
- Basic to RAID 1
- Basic to RAID 5
- RAID 1 to RAID 5
- RAID 5 to RAID 6
|
| Volume Expansion with Larger HDDs |
- Synology Hybrid RAID
- RAID 1
- RAID 5
- RAID 6
|
| Volume Expansion by Adding a HDD |
- Synology Hybrid RAID
- RAID 5
- RAID 6
- JBOD
|
| Global Hot Spare Supported RAID Type |
- Synology Hybrid RAID
- RAID 1
- RAID 5
- RAID 6
- RAID 10
|
| SSD Support |
| SSD Read/Write Cache (White Paper) |
|
| SSD TRIM |
|
| File Sharing Capacity |
| Maximum User Accounts |
2048 |
| Maximum Groups |
256 |
| Maximum Shared Folder |
512 |
| Maximum Shared Folder Sync Tasks |
8 |
| Maximum Concurrent CIFS/AFP/FTP Connections |
512 |
| Windows Access Control List (ACL) Integration |
|
| NFS Kerberos Authentication |
|
| High Availability Manager |
|
| Log Center |
|
| Syslog Events per Second |
800 |
| Virtualization |
| VMware vSphere 5 with VAAI |
|
| Windows Server 2012 |
|
| Windows Server 2012 R2 |
|
| Citrix Ready |
|
| Notes |
Performance figures could vary on different environments. |
| Add-on Packages (See more) |
| Antivirus Essential |
|
| Antivirus by McAfee (Trial) |
|
| Audio Station |
|
| Central Management System |
|
| Cloud Station |
|
| Maximum Concurrent File Transfers |
512 |
| Cloud Sync |
|
| Directory Server |
|
| DNS Server |
|
| Download Station |
|
| Maximum Concurrent Download Tasks |
80 |
| Glacier Backup |
|
| HiDrive Backup |
|
| iTunes Server |
|
| Java Manager |
|
| Mail Server |
|
| Mail Station |
|
| Media Server |
|
| DLNA Certification |
|
| Note Station |
|
| Photo Station |
|
| RADIUS Server |
|
| Surveillance Station |
|
| Maximum IP cam (Licenses required) |
40 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264)* |
1200 FPS @ 720p (1280x800)
480 FPS @ 1080p (1920×1080)
250 FPS @ 3M (2048x1536)
200 FPS @ 5M (2591x1944) |
| Total FPS (MJPEG)* |
300 FPS @ 720p (1280x800)
150 FPS @ 1080p (1920×1080)
100 FPS @ 3M (2048x1536)
60 FPS @ 5M (2591x1944) |
| Time Backup |
|
| Maximum Task Number |
8 |
| Video Station |
|
| Video Transcoding |
Group 1 (See more) |
| VPN Server |
|
| Maximum Connections |
20 |
| Notes |
Surveillance Station throughput is tested with Axis P1347 (1280X720); FPS set to 30 at every channel. |
| Environment & Packaging |
| Environment |
RoHS Compliant |
| Packaging Content |
- Main Unit X 1
- Welcome Note X 1
- Accessory Pack X 1
- AC Power Cord X 1
- RJ-45 LAN Cable X 2
|
| Optional Accessories |
- Remote
- Camera License Pack
- 4GB DDR3 RAM Module
- Expansion Unit: DX1215 X 1
- VS240HD
|
