| Hardware Specifications |
| CPU |
| CPU Model |
Marvell Armada 370 |
| CPU Frequency |
1.2 GHz |
| Floating Point |
|
| Hardware Encryption Engine |
|
| Memory |
| System Memory |
512 MB DDR3 |
| Storage |
| Drive Bay(s) |
4 |
| Compatible Drive Type |
- 2.5" SATA(III) / SATA(II) HDD
- 2.5" SATA(III) / SATA(II) SSD
|
| Max. Internal Capacity |
8 TB (2 TB HDD X 4) (Capacity may vary by RAID types) (See All Supported HDD) |
| Hot Swappable Drive |
|
| External Ports |
| USB 3.0 Port |
2 |
| File System |
| Internal Drives |
EXT4 |
| External Drives |
- EXT4
- EXT3
- FAT
- NTFS
- HFS+ (Read Only, with max. volume size 2TB)
|
| Appearance |
| Size (Height X Width X Depth) |
120 mm X 105 mm X 142 mm |
| Weight |
0.66 kg |
| Others |
| LAN Number (RJ45) |
Gigabit X 2 |
| Link Aggregation |
|
| Wake on LAN/WAN |
|
| System Fan |
60 mm X 60 mm X 1 pcs |
| Easy Replacement System Fan |
|
| Wireless Support (dongle) |
|
| Noise Level |
21.8 dB(A) |
| Power Recovery |
|
| Scheduled Power On/Off |
|
| Power Supply Unit / Adapter |
30W |
| AC Input Power Voltage |
100V to 240V AC |
| Power Frequency |
50/60 HZ, Single Phase |
| Power Consumption |
15.48W (Access)
11.04W (HDD Hibernation) |
| Temperature |
| Operating Temperature |
5°C to 35°C (40°F to 95°F) |
| Storage Temperature |
-10°C to 70°C (15°F to 155°F) |
| Relative Humidity |
5% to 95% RH |
| Certification |
- FCC Class B
- CE Class B
- BSMI Class B
|
| Warranty |
2 Years |
| Notes |
- Power consumption is measured when fully loaded with Seagate 500GB ST9500325AS hard drive(s).
- Noise Level Testing Environment: Fully loaded with Seagate 500GB ST9500325AS hard drive(s) in idle; Two G.R.A.S. Type 40AE microphones, each set up at 1 meter away from the Synology NAS front and rear; Background noise: 17.2 dB(A); Temperature: 23.6˚C; Humidity: 58.2%.
|
| DSM Specifications |
| Storage Management |
| Max File System Size |
16 TB |
| Max Internal Volume Number |
256 |
| Max iSCSI Target Number |
10 |
| Max iSCSI LUN |
10 |
| Supported RAID Type |
- Synology Hybrid RAID
- Basic
- JBOD
- RAID 0
- RAID 1
- RAID 5
- RAID 6
- RAID 10
|
| RAID Migration |
- Basic to RAID 1
- Basic to RAID 5
- RAID 1 to RAID 5
- RAID 5 to RAID 6
|
| Volume Expansion with Larger HDDs |
- Synology Hybrid RAID
- RAID 1
- RAID 5
- RAID 6
|
| Volume Expansion by Adding a HDD |
- Synology Hybrid RAID
- RAID 5
- JBOD
|
| Global Hot Spare Supported RAID Type |
- Synology Hybrid RAID
- RAID 1
- RAID 5
|
| File Sharing Capacity |
| Max User Accounts |
2048 |
| Max Groups |
256 |
| Max Shared Folder |
256 |
| Max Shared Folder Sync Tasks |
2 |
| Max Concurrent CIFS/AFP/FTP Connections |
128 |
| Windows Access Control List (ACL) Integration |
|
| Log Center |
|
| Syslog Events per Second |
100 |
| Notes |
- Performance figures could vary on different environments.
- The Max File System size (or the Max Volume size) doesn't equal to the Max Internal Capacity, which is limited by the aggregated space of installed drives.
|
| Add-on Packages |
| Antivirus Essential |
|
| Audio Station |
|
| Cloud Station |
|
| Maximum Concurrent File Transfers |
128 |
| Cloud Sync |
|
| Directory Server |
|
| DNS Server |
|
| Download Station |
|
| Maximum Concurrent Download Tasks |
30 |
| Glacier Backup |
|
| HiDrive Backup |
|
| iTunes Server |
|
| Java Manager |
|
| Mail Server |
|
| Mail Station |
|
| Media Server |
|
| DLNA Certification |
|
| Photo Station |
|
| RADIUS Server |
|
| Surveillance Station |
|
| Max IP cam (Licenses required) |
8 (including 2 Free License) (See All Supported IP Cameras) |
| Total FPS (H.264) |
240 FPS @ VGA (640x480)
200 FPS @ 720p (1280x800)
64 FPS @ 1080p (1920×1080)
32 FPS @ 3M (2048x1536)
8 FPS @ 5M (2591x1944) |
| Total FPS (MJPEG) |
120 FPS @ VGA (640x480)
120 FPS @ 720p (1280x800)
60 FPS @ 1080p (1920×1080)
32 FPS @ 3M (2048x1536)
20 FPS @ 5M (2591x1944) |
| Time Backup |
|
| Maximum Task Number |
2 |
| Video Station |
|
| Video Transcoding |
Group 2 |
| VPN Server |
|
| Maximum Connections |
5 |
| Notes |
Surveillance Station throughput is tested with Axis M1054 (1280X800); FPS set to 10 at every channel; Compression rate: 30%; Video Codec: MJPEG, H.264; Recording Type is conducted with Motion Detection Recording (By camera) and Continuous Recording; Actual performance may vary depending on camera settings and DiskStation loading. |
| Environment & Packaging |
| Environment |
RoHS Compliant |
| Packaging Content |
- Main Unit X 1
- Welcome Note X 1
- Accessory Pack X 1
- AC Power Adapter X 1
- RJ-45 LAN Cable X 2
|
| Optional Accessories |
- Remote
- Camera License Pack
- VS240HD
|
