CPU |
AnnapurnaLabs, an Amazon company Alpine AL-214, 4-core, 1.7GHz |
CPU Architecture |
32-bit ARM |
Floating Point Unit |
есть |
Encryption Engine |
есть |
System Memory |
2 GB SODIMM DDR3 (1 x 2 GB) |
Maximum Memory |
8 GB (1 x 8 GB) |
Memory Slot |
1 x SO-DIMM DDR3/DDR3L |
Flash Memory |
512 MB (Dual boot OS protection) |
Drive Bay |
4x 3.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
Hot-swappable |
есть |
SSD Cache Acceleration Support |
есть |
Gigabit Ethernet Port (RJ45) |
2 |
10 Gigabit Ethernet Port |
1 x 10GbE SFP+ |
Jumbo Frame |
есть |
USB 3.2 Gen 1 port |
3 |
Form Factor |
Tower |
LED Indicators |
Power, Status, LAN, USB, HDD1-4 |
Buttons |
Power, Reset, USB Auto Copy |
Dimensions (HxWxD) |
161 × 160 × 219 mm |
Weight (Net) |
2.03 kg |
Weight (Gross) |
3.46 kg |
Operating temperature |
0 - 40 °C (32°F - 104°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
90W Adapter, 100-240V |
Power Consumption: HDD Sleep Mode |
11.65 W |
Power Consumption: Operating Mode, Typical |
26.7 W
Tested with drives fully populated.
|
Fan |
1 x 120mm, 12VDC |
Sound Level |
19.5 db(A) |
System Warning |
Buzzer |
Kensington Security Slot |
есть |
Max. Number of Concurrent Connections (CIFS) |
400 |
