| Ordering P/N |
TES-1885U-D1531-32G
TES-1885U-D1531-64G
TES-1885U-D1531-16GR
TES-1885U-D1531-32GR
TES-1885U-D1531-128GR |
| CPU |
Intel® Xeon® Processor D-1531, 6-core 2.2 GHz |
| System memory |
Total DIMM slots: 4
Maximum memory: DDR4 128 GB ( 32 GB RDIMM x 4 )
Memory modules pre-installed:
TES-1885U-D1531-32G: 32 GB non-ECC RAM ( 16 GB UDIMM x 2 )
TES-1885U-D1531-64G: 64 GB non-ECC RAM (16 GB UDIMM x 4 )
TES-1885U-D1531-16GR: 16 GB ECC RAM ( 8 GB RDIMM x 2 )
TES-1885U-D1531-32GR: 32 GB ECC RAM ( 8 GB RDIMM x 4 )
TES-1885U-D1531-128GR: 128 GB ECC RAM ( 32 GB RDIMM x 4 )
Note: TES-1885U requires at least 32GB RAM for running QES operating system. |
| Flash Memory |
4 GB DOM |
| Hard Drive Tray |
Front: 2.5" / 3.5" x 12
Rear: 2.5" SSD slot x 6 |
| Supported Hard Drive |
Front: SAS 12Gb/s, SAS 6Gb/s, SATA 6Gb/s HDD and SSD
Rear: SATA 6Gb/s SSD |
| LAN Port |
2 x SFP+ 10GbE ports, 4 x Gigabit ports |
| LED Indicators |
10 GbE, Status, LAN, Storage expansion port status |
| Buttons |
System: Power button and reset button |
| Form Factor |
2U, Rackmount |
| Dimensions (H x W x D) |
88 x 442.5 x 530.5 mm
3.46 x 17.42 x 20.89 inch |
| Weight |
Net weight (NAS only): 15.1 kg / 32.28 lb
Gross weight (with packing and accessories): 21.41 kg / 47.20 lb |
| Temperature |
0-40˚C |
| Relative Humidity |
5~95% non-condensing, wet bulb: 27˚C. |
| Power Supply |
Redundant power: Input 90~264VAC; 450W x 2 |
| PCIe Slot |
Number: 4
Slot 1: PCIe Gen.3 x8
Slot 2: PCIe Gen.2 x4
Slot 3: PCIe Gen.3 x4
Slot 4: PCIe Gen.3 x4 or PCIe Gen.3 x8
Note: Slot 4 provides the width of PCIe Gen.3 x8 when slot 3 is not in use. Slot 4 then provides the width of PCIe Gen.3 x4 only when an expansion board is installed in slot 3. |
| Fan |
4 x 6 cm smart cooling fan |
