CPU |
TVS-1582TU-i5-16G: Intel® Core™ i5-7500 3.4 GHz quad-core processor
|
System memory |
Total DIMM slots: 4
Maximum memory: 64 GB (16 GB x4)
TVS-1582TU-i5-16G:
System memory: 16 GB DDR4 RAM
Memory modules pre-installed: 8 GB x2
|
Flash Memory |
512MB DOM |
Hard Drive Tray |
6 x 2.5" SSD
9 x 2.5"/3.5" hard drive or SSD |
Drive Interface |
SATA 6Gbps/3Gbps; Hot-swappable |
Thunderbolt Port |
4 x Thunderbolt 3 port |
USB |
4 x USB 2.0 port (Rear)
4 x USB 3.0 port (Rear) |
LAN Port |
2 x SFP+ 10GbE port
4 x GbE port |
HDMI Output |
1 (HDMI 1.4b x1) |
LED Indicators |
System status, 2.5" SSD, 3.5" HDD |
Buttons |
System: Power button, Reset button |
System Warning |
Buzzer |
Form Factor |
2U rackmount |
Dimensions (H x W x D) |
88 x 442.5 x 530.5 mm
3.46 x 17.42 x 20.89 inch |
Weight |
Net weight (NAS only): 14.18 kg/ 31.26 lb
Gross weight (with packing and accessories): 21.41 kg/ 47.20 lb |
Sound Level (dB) |
Sound pressure (LpAm) (bystander position): 53.9 dB
(with 9 x Seagate ST2000VN000-1HJ164 hard drive and 6 x Seagate ST500LT012 SSD installed) |
Temperature |
0-40˚C |
Relative Humidity |
5~95% non-condensing, wet bulb: 27˚C |
Power Supply |
Redundant power: Input 90~264VAC; 450W x 2 |
PCIe Slot |
3 (1* PCIe Gen3 x8; 2* PCIe Gen3 x4) Note: Three PCle slots are occupied by two Thunderbolt™ 3 card and a 10GbE adapter. |
Fan |
4 x 6 cm smart cooling fan |
