| Host Interface |
Three SAS 6Gbps 4x wide port (SFF-8644) |
| Drive Bay |
16 x 3.5-inch SATA 6Gb/s, 3Gb/s hard drives or 2.5-inch SATA SSDs |
| LED Indicators |
Front panel: Status, fault, system over heat, fan error
Rear panel: SAS link, SAS error, enclosure ID |
| Form Factor |
3U rackmount |
| Dimensions (H x W x D) |
130 x 442.4 x 528.3 mm
5.12 x 17.42 x 20.80 inch |
| Weight |
Net weight (NAS only): 18.14 kg/39.99 lb
Gross weight (with packing and accessories): 25.92 kg/57.14 lb |
| Sound Level |
Sound pressure (LpAm): 36.7 dB(A) |
| Operating Temperature & Relative Humidity |
0 ~ 40C ( 32F ~ 104F ), 5 ~ 95% RH non-condensing, wet bulb: 27C (80.6F) |
| Power Consumption (W) |
In Operation 204.4 W |
| Power Supply Unit |
Redundant/Hot Swap ATX Power Supply, 650 W, 90-240 Vac~, 50-60 Hz |
| Fan |
3 x 6 cm smart cooling fan (hot-swappable fan module) |
HDD Seagate SAS ST2400MM0129
