CPU |
Intel® Xeon® D-1602 dual-core 2.50 GHz processor (burst up to 3.2 GHz) |
CPU Architecture |
64-bit x86 |
System Memory |
4 GB UDIMM DDR4 ECC (1 x 4GB) |
Maximum Memory |
128 GB (4 x 32 GB) |
Memory Slot |
4 x Long-DIMM DDR4 |
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
Front: 12 x 3.5-inch SATA 6Gb/s, 3Gb/s
Rear: 6 x 2.5-inch SATA 6Gb/s, 3Gb/s |
Drive Compatibility |
3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
2.5-inch bays:
2.5-inch SATA solid state drives |
Hot-swappable |
|
SSD Cache Acceleration Support |
|
Gigabit Ethernet Port (RJ45) |
4 |
10 Gigabit Ethernet Port |
2 x 10GbE SFP+ SmartNIC port
Pre-installed with a 10GbE PCIe adapter
|
PCIe Slot |
4
Slot 1: PCIe Gen 3 x4
Slot 2: PCIe Gen 3 x8 or x4
Slot 3: PCIe Gen 3 x4
Slot 4: PCIe Gen 3 x8 or x4
*Slot 4 is preinstalled with a 10GbE network adapter.
**Slot 2 provides the width of PCIe Gen 3 x8 when Slot 1 is not in use, and provides the width of PCIe Gen 3 x4 when Slot 1 is in use.
***Slot 4 provides the width of PCIe Gen 3 x8 when Slot 3 is not in use, and provides the width of PCIe Gen 3 x4 when Slot 3 is in use.
|
USB 3.2 Gen 1 port |
2 |
Form Factor |
Rackmount |
LED Indicators |
HDD, SSD, Status, LAN, storage expansion port status |
Buttons |
Power, Reset |
Dimensions (HxWxD) |
3.48 × 18.98 × 21.64 inch |
Weight (Net) |
28.06 lbs |
Weight (Gross) |
41.2 lbs |
Operating temperature |
0 - 40 °C (32°F - 104°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
550W(x2), 100-240V |
Power Consumption: Operating Mode, Typical |
117.92 W |
Fan |
System fan: 3 x 60mm, 12VDC |
Sound Level |
56.9 db(A) |
System Warning |
Buzzer |
