| torage |
|
| Disk Slot Number |
6 |
| Compatible Disk Types |
3.5" SATA HDD |
| 2.5" SATA HDD |
| 2.5" SATA SSD |
| File System |
NTFS, APFS, Mac OS,FAT32,EXT4,exFAT |
| Maximum Internal Raw Capacity |
132 TB (22 TB drive x 6) (Capacity will vary along with the RAID type) |
| RAIDs Supported |
SINGLE DISK |
| Hardware RAID |
/ |
| RAID Manager Software |
/ |
| RAID Manager Software Language |
/ |
| RAID Online Expansion |
/ |
| RAID Migration |
/ |
| RAID Auto-rebuilding |
/ |
| Drive Hot Swap |
√ |
| HDD Sleep |
√ |
| HDD S.M.A.R.T. Inspection |
/ |
| Sector Inspection and Parity Check |
/ |
| SSC Cache |
/ |
| Daisy Chain |
/ |
| HDD NCQ Technology |
/ |
| Alert Notice |
/ |
| Event Log |
/ |
| External Ports |
|
| USB |
USB3.2 Type-C gen2 10Gbps |
| Thunderbolt |
/ |
| DP Interface |
/ |
| Network Interface |
/ |
| USB HOST Interface |
/ |
| Power Socket |
DC IN 12V |
| Reading/writing Speed (max.) |
|
| Reading Speed (max.) |
Read520MB/s ( SSD* 1 ); Read1016MB/s ( SSD* 6 ) |
| Writing Speed (max.) |
Write500MB/s ( SSD*1 ); Write986MB/s ( SSD*6 ) |
| Appearance |
|
| Size (H*W*D) |
226 x 130 x 218 mm |
| Packaging Size (H*W*D) |
325 x 210 x 282 mm |
| Weight |
net weight: 3.4 Kg Gross Weight: 4.5 Kg |
| Others |
|
| System fan |
80 mm x 80 mm x25mm (x 2) |
| Fan mode |
Smart |
| Noise Level |
28.4dB(A) |
| Power Supply |
|
| Power Supply |
120 W |
| AC Input Voltage |
100V to 240V AC |
| Current Frequency |
50/60 HZ, Single Phase |
| Power Consumption |
2.0 W(Access) |
| Environment Temperature |
|
| Working Temperature |
0°C ~ 40°C (32°F ~ 104°F) |
| Storage Temperature |
-20°C ~ 60°C (-5°F ~ 140°F) |
| Relative Humidity |
5% ~ 95% RH |
| Supported OS |
Windows OSMac OS |
| Warranty |
2 years |
| Certificate |
CE, FCC, CCC, KC |
| Environment |
RoHS compliance |
| Package Contents: |
Host unit (x1) |
| Power cord (x1) |
| USB Cable C to Type-C(10Gb) (x1) |
| Quick Installation Guide (x1) |
| Power adapter (x1) |
| Screws (several) |
| Limited Warranty Note x 1 |
