| | ARECA PCI-Express RAID Card Comparison | | Model Name | ARC-1214-4I | ARC-1224-8I | | I/O Processor | ARM-based storage I/O processor | | Host Bus Type | PCIe 2.0 x8 Lanes | | Drive Connector | 1xSFF-8087 | 2xSFF-8087 | | Drive Support | Up to 4 x 6Gb/s SATA HDDs/SSD | Up to 8 x 6Gb/s SATA HDDs/SSD | | RAID Level | 0, 1, 1E, 3, 5, 6, 10, Single Disk, and JBOD | 0, 1, 1E, 3, 5, 6, 10, 30, 50, 60, Single Disk, and JBOD | | On-Board Cache | 1GB on-board SDRAM with ECC | | Management Port | In-Band: PCIe
Out-of-Band: LCD and LAN Port | | Enclosure Ready | Individual Activity/Faulty Header, Serial Bus and SGPIO | |
| | |
| | |
| | |
| | Adapter Architecture |
| |
| ARM storage I/O processor |
| | | 1GB on-board SDRAM with ECC |
| | | PCIe 2.0 x8 lanes host interface |
| | | Support up to 4/8 internal 6Gb/s SATA physical links |
| | | ARC-1214-4I supports up to 4 x 6Gb/s SATA HDDs |
| | | ARC-1224-8I supports up to 8 x 6Gb/s SATA HDDs |
| | | Multi-adapter support for large storage requirements |
| | | BIOS boot support for greater fault tolerance |
| | | BIOS PnP (plug and play) and BBS (BIOS boot specification
support |
| | | Support EFI BIOS for Mac Pro |
| | | NVRAM for RAID event & transaction log |
| | | Redundant flash image for controller availability |
| | | Battery Backup Module (BBM) ready (Optional) |
| | | RoHS compliant |
| | |
| | RAID Features |
| | | RAID level 0, 1, 10(1E), 3, 5, 6, 30, 50, 60, Single Disk or JBOD |
| | | Multi-level RAID 0 and RAID 10 (R00 and R100) |
| | | Support up to 1MB stripe size |
| | | Multiple RAID selection |
| | | Online array roaming |
| | | Online RAID level/stripe size migration |
| | | Online capacity expansion and RAID level migration simultaneously |
| | | Online volume set growth |
| | | Instant availability and background initialization |
| | | Support global and dedicated hot spare |
| | | Automatic drive insertion/removal detection and rebuilding |
| | | Greater than 2TB capacity per disk drive support |
| | | Greater than 2TB per volume set (64-bit LBA support) |
| | | Support intelligent power management to save energy and
extend service life |
| | | Multiple pairs SSD/HDD disk clone function |
| | | SSD automatic monitor clone (AMC) support |
| | |
| | Monitors/Indicators |
| | | System status indication through global HDD activity/fault connector, individual fault connector, LCD/serial bus connector and alarm buzzer |
| | | SMTP support for email notification |
| | | SNMP support for remote manager |
| | | Enclosure management (Serial bus and SGPIO) ready |
| | |
| | RAID Management |
| | | Field-upgradeable firmware in flash ROM |
| | | In-Band Manager |
| | | Hot key "boot-up" McBIOS RAID manager via M/B BIOS |
| | | Web browser-based McRAID storage manager via ArcHttp proxy server for all operating systems |
| | | Support Command Line Interface (CLI) |
| | | API library for customer to write monitor utility |
| | | Single Admin Portal (SAP) monitor utility |
| | | Out-of-Band Manager |
| | | Firmware-embedded web browser-based McRAID storage manager, SMTP manager, SNMP agent and Telnet function via Ethernet port |
| | | API library for customer to write monitor utility |
| | | Support push button and LCD display panel (Optional) |
| | | |
| | Operating System |
| | | Windows 8/2012/7/2008/Vista/XP/2003 |
| | | Linux |
| | | FreeBSD |
| | | VMware |
| | | Solaris 10/11 x86/x86_64 |
| | | Mac OS 10.5.x/10.6.x/10.7.x/10.8.x |
| | | |
| | Environmental/Physical |
| | Mechanical |
| | | Dimension: | ARC-1214-4I/1224-8I: 62(H) x 168(L) mm | |
| | | |
| | Environmental Specifications |
| | | Operating: | Temperature:+5°c to +50°c | | | Humidity: 15-80% | | | non-condensing | | | Temperature: +5 c to +60 c
Humidity: 15-80%, non-condensing | | | | Storage Temperature: | Temperature:-40°c to 70°c | | | Humidity: 5-90% | | | non-condensing | |
| | | |
| | Electrical |
| | | Power Requirements: | On 3.3 V: 4.95W | | | On+12V: 6.22W | |
