| IO Controller |
LSISAS2308/ Fusion MPT 2.0 |
| Storage Connectivity; Data Transfer Rates |
8 ports; 6Gb/s SAS 2.1 compliant |
| SAS Bandwidth |
Half Duplex
600 MB/s per lane |
| Port Configurations |
8 ea, x1 ports (individual drives)-or-
2 ea, x4 wide port
|
| Host Bus |
X8 lane, PCI Express 3.0 compliant |
| PCI Data Burst Transfer Rates |
Half Duplex
X8, PCIe 8000 MB/s |
| Physical Dimensions |
Low Profile (2. 6” x 6.6”) |
| Connectors |
Two Mini-SAS internal connectors (SFF8087) |
| Brackets |
Full height and low profile |
| Cable Support |
Passive Copper |
| Operating Voltage |
+12V +/-8%; 3.3V +/-8% |
| PCI Power (Nominal) |
9.8W typical, Airflow 200 LFM |
| Device Support |
256 Non-RAID SAS/SATA devices |
| Integrated RAID (IR) |
|
|
| RAID 0 |
10 per volume |
| RAID 1 |
2 per volume plus hot spare |
| RAID 1E |
10 per volume |
| RAID 10 |
10 per volume |
|
| Environmental |
| Operating |
Storage |
| 0°C to 55°C |
-45°C to 105°C |
| 5 to 90% Non-condensing |
5 to 90% Non-condensing |
|
| MTBF |
>2,000,000 Hours |
| Regulatory Certifications |
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New Zealand (AS/NZS 3548); Safety: EN60950; RoHS; WEEE |
| OS Support |
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware, FreeBSD
See //www.lsi.com/support/pages/downloads.aspx for details on versions
|
