IO Controller |
Two, LSISAS2308/Fusion MPT 2.0 |
Storage Connectivity; Data Transfer Rates |
16 ports; 6Gb/s SAS 2.1 compliant |
SAS Bandwidth |
Half Duplex
2400MB/s, x4, 6Gb/s SAS lanes
|
Port Configurations |
16 ea, x1 ports (individual drives)
4 ea, x4 wide ports
2ea, x8 wide ports
|
Host Bus |
x8 lane, PCI Express 3.0 compliant |
PCI Data Burst Transfer Rates |
Half Duplex
8000MB/s, x8, PCIe 3.0
|
Physical Dimensions |
68.90x167.65 mm |
Connectors |
Four (x4) mini-SAS HD external connectors (SFF8644) |
Brackets |
Full height and low profile |
Cable Support |
Passive Copper |
Operating Voltage |
+12V +/-8%; 3.3V +/-9% |
PCI Power (Nominal) |
25.8W |
Device Support |
1024 Non-RAID SAS/SATA devices |
Environmental |
Operating |
Storage |
0°C to 55°C |
-45°C to 105°C |
5 to 90% Non-condensing |
5 to 90% Non-condensing |
|
MTBF |
>1,300,000 Hours |
Regulatory Certifications |
EMC: Class B-US (CFR 47, P15B); Canada (ICES-003); Japan (V-3/02.04); Europe (EN55022/EN55024); Australia/New Zealand (AS/NZS 3548); Korea (N-B 2-0001-404); Safety: EN60950; RoHS; WEEE |
OS Support |
Microsoft Windows, Linux (SuSE , Red Hat), Solaris, VMware, FreeBSD
See www.lsi.com/support/Pages/Download-Search.aspx for details on versions
|
