Каталог - Дисковые массивы - Дисковые массивы SAS - Дисковый массив HP MSA 2040 Energy Star SAS Dual Controller LFF Storage/S-Buy (K2R83SB)



Дисковый массив HP MSA 2040 Energy Star SAS Dual Controller LFF Storage/S-Buy (K2R83SB)

Цена: по запросу
Наличие: Под заказ
Артикул: K2R83SB
Производитель:Hewlett Packard



Changing storage needs for server customers now requires greater levels of performance and functionality at a lower cost of ownership. The next generation HPE MSA 2040 Storage arrays raises the bar & uniquely addresses HPE ProLiant customers' shared storage and data protection needs, reduces TCO while dramatically increasing performance using technologies such as Solid State Drives, Snap and Volume copy, Replication and SEDs.

The MSA 2040 Storage arrays are positioned to provide an excellent value for customers needing increasing performance to support initiatives such as consolidation and virtualization. The MSA 2040 delivers this performance by leveraging new controller architecture with a new processor, four ports with 4GB cache per controller & using drive technologies such as SSDs.

The MSA 2040 Storage ships standard with 64 Snapshots and Volume Copy enabled for increased data protection and allow replication with optional Remote Snap software between arrays (FC or iSCSI only).

Features

Simple: Flexible Architecture. Easy to Setup. Easy to Manage

Choice of 8 Gb/16 Gb FC, 1 Gb/10GbE iSCSI and 12 Gb SAS to match the configuration needs of infrastructure.

Deploy single or dual controllers depending on high-availability and budgetary requirements.

Select disk enclosures with Large or Small Form Factor drives –choice of High-performance Solid State Drives, Enterprise-class SAS or SAS Midline drives or Self-Encrypting Drives (SED) based on application, performance and budget needs.

The integrated setup and management tools for MSA are easy to manage for HPE ProLiant/BladeSystem IT managers.

Fast: MSA 2040 Sets New Standards for $/IOPS in Entry SAN, 3x to 4x Today’s Competition

New high-performance Converged SAN controller and SAS controller offer 4x the performance of today's other entry-level SAN arrays.

4-port Converged SAN controller supporting Fibre Channel and iSCSI and a SAS Controller with 4GB Cache translating into better application response time and ability to support more virtualized environments.

SSD support with integrated “wear gauge” helps improves application performance and allows customers to reduce their operating costs by reducing foot prints and power consumptions.

Self-Encrypting Drives (SEDs) designed to safeguard critical personal and business information and to comply with regulatory mandates.

Futureproof: 2x the Bandwidth and the First Entry SAN with 16 Gb FC

Choice of 8 Gb/16 Gb FC, 1 Gb/10GbE iSCSI and 12 Gb SAS to match the configuration needs of infrastructure.

The 4th generation of MSA’s unique Data-in-Place upgrades provides investment protection.

Host ports upgradeable by SFPS (8 Gb/16 Gb FC) or (1 GB/10GbE iSCSI) allows customers to manage their total cost of ownership lower.

ENERGY STAR Certified: MSA 2040 is Now ENERGY STAR Certified

ENERGY STAR certified power supplies will lead to energy consumption efficiencies translated into savings or regulatory rebates for customers.

  • Microsoft® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • SUSE® is a registered trademark of Suse.
  • ESXi™ is a trademark of VMware, Inc. in the United States and/or other jurisdictions.
  • Hyper-V® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • Linux® is a registered trademark of Linus Torvalds.
  • SUSE® is a registered trademark of Suse.
  • VMware® is a registered trademark of VMware, Inc. in the United States and/or other jurisdictions.
  • ENERGY STAR® a registered mark owned by the U.S. government.

Specifications



Capacity
  • 96TB Raw
  • Supported
Drive description
  • (12) LFF SAS/MDL SAS/SSD
Host interface
  • 12Gb/sec SAS (4) Ports per controller or
  • Included
Storage controller
  • (2) MSA 2040 SAS Controller
Storage expansion options
  • HPE MSA 2040 Energy Star LFF Disk Enclosure or D2700 2.5-inch disk enclosure
Clustering support
Windows, Linux, HP-UX, OpenVMS
Compatible operating systems
  • Microsoft Windows Server 2012
  • Microsoft Windows 2008
  • Microsoft Windows Hyper-V
  • HP-UX
  • Red Hat Linux
  • SUSE Linux
  • VMware ESXi 5.x
  • VMware ESXi 6.x
  • Detailed information available at: http://www.hp.com/storage/spock
Form factor
  • 2U

Dimensions and weight



Dimensions (W x D x H)
73.6 x 66 x 28 cm

What's included



Differentiator
  • Pre-Config array with (2) MSA 2040 SAS Controllers in a Large Form Factor (LFF) Chassis - 12 drive bay Chassis
Warranty - year(s) (parts/labor/onsite)
  • 3/0/0
What's in the box
  • MSA 2040 Energy Star SAS Dual Controller LFF Storage
  • Microsoft® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • SUSE® is a registered trademark of Suse.
  • ESXi™ is a trademark of VMware, Inc. in the United States and/or other jurisdictions.
  • Hyper-V® is a registered trademark of Microsoft Corporation in the United States and other countries.
  • Linux® is a registered trademark of Linus Torvalds.
  • SUSE® is a registered trademark of Suse.
  • VMware® is a registered trademark of VMware, Inc. in the United States and/or other jurisdictions.
  • ENERGY STAR® a registered mark owned by the U.S. government.
