| Chassis format |
All-in-one (dual controllers, internal drive bays, networking) with expansion options |
| Rack size |
3U |
| Controllers |
2 hot-swappable per chassis (dual active) |
| Processors |
Intel® Xeon® Processor E5-2603v4, 1.7GHz, 6 cores |
| Internal storage capacity |
SCv3000: 16 x 3.5” drive bays SCv3020: 30 x 2.5” drive bays |
| System memory |
32GB per SCv3xxx array (16GB per controller) |
| Operating system |
Dell Storage Center OS (SCOS) 7.2 or greater |
| Supported expansion enclosures |
SCv300: 16 x 3.5” drive bays (12Gb SAS) SCv320: 30 x 2.5” drive bays (12 Gb SAS) SCv360: 60 x 3.5” drive bays (12Gb SAS) |
| Maximum drive count |
222 (internal plus external expansion), more in federated systems |
| Max raw capacity |
1PB per array (SSD or HDD) 7, more in federated systems |
| Max raw capacity (NAS) |
1 PB per array with optional Dell EMC NX3000 Series Windows NAS appliance |
| Storage media |
SAS and NL-SAS drives; different drive types, transfer rates, rotational speeds can be mixed in the same system. SSD: write-intensive and read-intensive drives HDD: 15K, 10K, 7.2K RPM |
| Front-end-network protocols |
FC, iSCSI, SAS (supports simultaneous multiprotocol) Up to 16 FE ports per array, more in federated systems |
| Max 16Gb FC ports |
8 per array (SFP+) |
| Max 10Gb/1Gb iSCSI ports |
Up to 8 SFP+ or BaseT ports per array |
| Max 12Gb SAS ports |
Up to 8 12Gb SAS ports |
| Management ports |
2 per array (1Gb BASE-T) |
| Back-end expansion protocols |
12Gb SAS |
| Back-end expansion ports |
4 12Gb SAS (wide-Port) per array Up to 16 expansion enclosures per array, more in federated systems |
